Engineered for large-scale agricultural operations, our H-type laying hens breeding equipment represents a comprehensive, multi-tiered automated feeding ecosystem. Developed with precision by Hezhengyuan, this modular architecture can be customized from 3 to 12 tiers to perfectly align with your facility's spatial requirements and operational scale. Beyond basic housing, this integrated solution encompasses advanced egg collection, automated feeding and hydration lines, efficient feces removal, optimized lighting, and intelligent environmental control. Driven by advanced Internet of Things (IoT) modules, the entire setup ensures optimal animal health, maximizes egg production performance, and maintains strict environmental standards. By transforming a traditional poultry house into a highly controlled, data-driven environment, farm operators can significantly reduce manual labor while securing a more predictable and profitable yield.
The laminated H-type frame design is structurally engineered for maximum stability and firmness. By utilizing vertical space effectively, this system allows for an exceptionally high feeding density. This intensive rearing approach minimizes land usage and drastically reduces overhead costs, translating to substantial savings on initial infrastructure investment and a significantly faster return on investment for large-scale farm operators.
Operating with remarkable stability, the integrated egg collection mechanism is designed to handle high-volume outputs with gentle precision. Capable of processing up to 20,000 eggs per hour, the system boasts a remarkably low breaking rate of under 0.2%. This high degree of automation not only streamlines daily operations but also protects your yield, ensuring that every egg reaches the collection point intact and clean.
A premium front filter device is installed to guarantee pristine, clean water quality throughout the entire drinking line. Each individual cage unit is equipped with two responsive stainless steel nipples, providing an adequate and continuous water supply. The intuitive design makes it exceptionally easy for the birds to drink, promoting better hydration and overall flock health without the risk of water stagnation.
Maintaining a sanitary environment is effortless with our advanced cleaning system. Constructed with high corrosion resistance materials, the structure is thoughtfully designed to ensure the thorough scraping and clearing of the manure belt. This continuous removal process prevents ammonia buildup, eliminates foul odors, and significantly reduces the labor required for daily facility maintenance.
Our environmental control system features a high degree of microcomputer intelligence, fluidly integrating ventilation, cooling, and humidity management. By providing a consistently comfortable living environment, it actively reduces heat stress and the risk of airborne diseases. This proactive climate management lowers the flock mortality rate and directly improves the overall egg production rate, keeping the birds active and healthy.
To further enhance hygiene, a specialized V-shaped water tank is configured directly beneath the drinking lines. This strategic placement effectively catches any stray water droplets, preventing them from falling onto the manure belt below. As a result, the water content of the chicken manure remains exceptionally low, making the waste much easier to handle and process for secondary agricultural uses.
Premium Q235 Steel Construction: The entire cage system is manufactured from international standard high-strength Q235 steel, treated with a rigorous hot-dip galvanized and aluminum-zinc coating process. This provides incredibly strong corrosion resistance, ensuring the structural integrity of the equipment and extending its reliable service life to an impressive 15 to 30 years, even in high-humidity agricultural environments.
Advanced Mesh Welding Technology: All cage meshes are meticulously crafted using aluminum-plated zinc wire welding. The resulting surface offers a smooth, tactile finish that prevents bird injury, while its corrosion resistance is proven to be 3 to 4 times greater than that of standard hot-dip galvanized wire mesh, guaranteeing long-term durability.
Secure Sliding Cage Doors: The architectural structure of the sliding cage doors facilitates smooth, effortless operation during daily inspections or flock management. This secure locking mechanism effectively prevents birds from escaping or becoming trapped, ensuring a safe enclosure that minimizes stress and physical harm to the laying hens.
Pure PVC V-Shaped Feed Troughs: Designed with high structural strength and a wide cross-section, the pure PVC rolled feed troughs are built to withstand constant use without warping. The V-shape design actively saves feed by preventing birds from throwing their meals, eliminates corners where mildew can form, and significantly improves the overall feed conversion rate.
Optimized Bottom Net Angle: The flooring of each cage features a precisely calculated slope. This reasonable angle ensures that freshly laid eggs roll gently and smoothly onto the automated egg belt without gaining excessive speed, effectively reducing the rate of egg damage and preserving the integrity of the shell.
Integrated Waste Management Components: Supported by heavy-duty U-shaped steel brackets, a secondary V-shaped water trough is arranged under the drinking line to catch drips. This works in tandem with our high-strength PP composite manure cleaning belts, keeping the waste dry and ensuring the entire waste management process operates smoothly without belt slippage or degradation.
parameter | Unit | HZYLCS Chain | HZYLCS Hopper |
Standard height/tier | mm | 640/700 | 640/700 |
Unit depth D | mm | 600/650 | 600/650 |
Unit width L | mm | 603 | 603 |
Unit door height H1 | mm | 234 | 234 |
Unit front height H2 | mm | 460 | 460 |
Bottom mesh sqcm | cm2 | 3618/3919 | 3618/3919 |
Number of birds/unit | bird/cage | 8-9 | 8-9 |
Space/bird S | cm2 | 402/452-435/490 | 402/452-435/490 |
Cage width L2 | mm | 1200/1300 | 1200/1300 |
System width L1 | mm | 1590/1690 | 1630/1730 |
As a dedicated manufacturer of large-scale agricultural equipment, we understand that supply chain reliability is just as critical as product performance. Our production facilities are fully certified under ISO9001 and CE international quality and safety systems, ensuring that every tier of our H-type laying hens breeding equipment meets rigorous global market entry and strict quality control standards.
To support extensive agricultural projects worldwide, we maintain a highly efficient monthly production capacity that guarantees a standard delivery cycle, even for high-volume orders. Every system is meticulously packed according to strict export packaging standards, protecting sensitive components like microcomputer controllers, large-capacity feed silos, and PVC troughs from moisture and physical impact during sea transit. We accommodate a variety of international trade terms, providing a streamlined procurement experience that empowers farm operators to scale their operations with absolute confidence.
