7090 & 7060 Type Aluminium Alloy Cooling Pad System For Efficient Ventilation

7090 & 7060 Type Aluminium Alloy Cooling Pad System - High-Efficiency Evaporative Cooling Solution

Engineered for superior heat dissipation, the 7090 & 7060 Type Aluminium Alloy Cooling Pad System delivers energy-efficient evaporative cooling with optimized airflow. Its corrosion-resistant aluminium construction ensures durability in harsh environments while reducing operational costs.

- Compact 7mm flute design with 45° corrugation angle for enhanced airflow
- Eco-friendly water-based cooling technology, eliminating harmful refrigerants
- Modular design (up to 2000mm height x 600mm width) for flexible installations
- Ideal for agriculture (poultry/livestock) and industrial applications (warehouses/factories)

Availability:

Quantity:



Inquire Add to Basket

Product Description

Overview

The 7090 and 7060 Type Aluminium Alloy Cooling Pad Systems are engineered to deliver efficient ventilation and reliable temperature reduction for demanding environments. Featuring a precise 7mm flute design and specialized corrugation angles, these systems effectively lower temperatures in confined spaces while maintaining optimal airflow dynamics. Constructed with a premium aluminium alloy frame, the cooling pad system offers superior resistance to corrosion, mineral scaling, and UV degradation. This robust construction ensures long-term operational stability even in challenging agricultural and industrial conditions. The 7090 and 7060 models are specifically developed for applications requiring both intensive cooling and air purification, providing a dependable solution for livestock facilities, manufacturing workshops, and large-scale greenhouse operations.

Core Features

1. Enhanced Airflow Dynamics: The meticulously engineered 7mm flute design allows for unrestricted air passage through the cooling media. This structural advantage significantly improves overall ventilation efficiency while minimizing static pressure drop, which directly translates to reduced energy consumption for exhaust fans.

2. Eco-Friendly Evaporative Cooling: Utilizing advanced evaporative technology, this system relies on water as its primary refrigerant. By avoiding harmful chemical coolants, it supports environmentally conscious facility management and helps lower overall carbon emissions during continuous operation.

3. Low Maintenance Requirements: The smooth aluminium surfaces and specialized pad structure naturally resist the buildup of mineral deposits and airborne particulate matter. This design requires minimal routine cleaning to sustain peak cooling performance, thereby reducing labor costs and facility downtime.

4. Modular and Scalable Design: Built for versatile integration, the cooling pad system features a modular architecture that accommodates flexible installation. It can be easily adapted to fit various architectural layouts, supporting seamless upgrades or replacements for existing ventilation setups.

5. High Durability Construction: The integration of industrial-grade aluminium alloy ensures exceptional resistance to rust, harsh chemicals, and extreme weather fluctuations. This structural integrity prevents frame warping and extends the overall service life of the cooling infrastructure, maximizing the return on investment for facility operators.

Applications

• Agriculture & Livestock: Provides essential cooling for poultry houses and pig farms, effectively reducing heat stress, improving feed conversion rates, and supporting overall livestock health during peak summer months.

• Industrial Settings: Maintains safe and comfortable ambient temperatures in manufacturing plants, warehouses, and heavy-duty workshops, which helps protect sensitive machinery and enhances worker productivity.

• HVAC System Integration: Serves as a highly efficient supplemental cooling stage when integrated with existing commercial ventilation systems, significantly reducing the operational reliance on traditional, energy-intensive air conditioning units.

• Commercial Kitchens: Delivers targeted cooling to high-temperature cooking areas and adjacent storage rooms, preventing equipment overheating and ensuring optimal environmental conditions for food safety.

• Horticulture & Greenhouses: Facilitates precise control over humidity and temperature within plant nurseries and vertical farming setups, optimizing the microclimate for accelerated and healthy plant growth.

Product Specifications & Dimensions

To meet diverse project requirements, the cooling pad system is available in precise configurations. We provide high-performance cooling pad papers with the following specific dimensions and options:

Thickness: 0.15m
Width: 0.6m
Standard Heights: 1m, 1.5m, 1.8m, and 2.0m (Can be seamlessly installed by heightening to accommodate taller facility walls).
Angle Models: 7090 Type (45° x 45°) and 7060 Type (45° x 15°).
Appearance Options: Available in conventional non-blackening finish and single-sided blackening finish, depending on specific light-restriction and aesthetic requirements.

The 7090 and 7060 Type Cooling Pad Systems offer a sustainable, cost-effective cooling solution for industries where energy efficiency, precise dimensions, and structural durability are paramount.

Service Advantage

At the core of our operations is a steadfast commitment to delivering exceptional service and tailored solutions for complex ventilation and cooling requirements. We understand that every facility has unique environmental conditions, spatial constraints, and performance demands. Therefore, we go beyond simply supplying standard products; we provide a comprehensive, end-to-end service ecosystem designed to support your project from the initial consultation phase through to final implementation. Our primary goal is to ensure that your procurement process is seamless and that your investment yields maximum operational efficiency and long-term value.

Customized Solutions & Collaborative Technical Support

We take immense pride in our capacity to offer highly customized solutions that directly address the specific challenges of our clients. Our dedicated technical team maintains close, continuous contact with you throughout the entire project lifecycle. We invest the time necessary to gain an in-depth understanding of your unique operational needs, facility dimensions, and climate control objectives. By thoroughly analyzing these specific requirements, we can engineer and deliver tailored products and services that align perfectly with your project specifications. This collaborative, consultative approach ensures that the ventilation solutions we provide are optimized for your exact demands, significantly reducing the risk of system incompatibility and enhancing overall cooling performance.

Innovative R&D and One-Stop Service Experience

To streamline your procurement and implementation process, we have developed a complete one-stop service model driven by innovative research and development. Our comprehensive support covers every critical phase of your project's execution. The process begins with meticulous material selection, ensuring that all foundational components possess the necessary durability and environmental resilience. From there, our advanced R&D capabilities inform the development of efficient, project-specific designs, culminating in expert installation guidance and support. By consolidating these essential services under one roof, we eliminate the complexities and potential miscommunications associated with managing multiple vendors. This integrated approach saves you valuable time and resources while ensuring a cohesive, efficient, and timely deployment of your cooling system.

Strict Quality Management and Equipment Stability

Reliability is a paramount concern for any industrial or commercial facility investing in cooling infrastructure. To guarantee exceptional product quality and enduring reliability, we have implemented a strict, comprehensive quality management system that governs every single stage of our production and service delivery. Every system component is subjected to rigorous inspections and testing protocols to ensure it meets our exacting standards for structural integrity and performance consistency. This unwavering focus on meticulous quality control directly translates to the long-term stability of the equipment we supply. By minimizing the likelihood of unexpected downtime and reducing ongoing maintenance requirements, our robust quality assurance processes are specifically designed to help customers maximize their investment benefits and maintain uninterrupted, efficient operations.

The certifications and qualifications we hold serve as a tangible testament to our rigorous quality control standards and our ongoing dedication to excellence in manufacturing and service delivery.

Customer-Centric Philosophy and Long-Term Value

We operate wholeheartedly with a focus on exceptional customer service, placing tangible user value at the absolute foundation of our business model. Our commitment to your success does not end with the delivery and installation of the product. We continuously strive to anticipate and meet your evolving operational needs, providing responsive after-sales support and proactive maintenance advice. By fostering strong, transparent, and trust-based relationships, we ensure complete customer satisfaction. We are dedicated to being not just a supplier, but a reliable, long-term partner in optimizing your facility's environment and operational efficiency.

aluminium alloy cooling pad cooling pad system 7090 type cooling pad 7060 type cooling pad evaporative cooling system
